INSTALLATION

Installation Solutions For a Healthier Living Space

Throughout our journey, we have always been committed to developing simple, quick and easy installation technologies for your textile floor coverings.

Innovations such as MaxTab adhesive tabs and PermaFuse XL carpet rolls allow floor coverings to be installed without the use of glue, bringing benefits that go far beyond simple and quick installation.

Installation Solutions FOR A DIRECT IMPACT ON YOUR ENVIRONMENT

  • Offer greater flexibility when improving or modifying your living spaces;
  • Optimize product integrity at the end of life to maximize the amount of recyclable materials;
  • Significantly reduce the presence of volatile organic compounds (VOCs) in your spaces.

WHAT IS MaxTab?

FLOATING AND GLUE-FREE

MaxTab is a patented adhesive tab that allows floating installation of our carpet tiles and planks without the application of odorous glues, thus eliminating the volatile organic compounds (VOCs) emitted by these liquid glues.

It’s easy to use, creates less mess and provides greater flexibility for installation, repair or selective replacement.

FLOATING AND GLUE-FREE

MaxTab is a patented adhesive tab that allows floating installation of our carpet tiles and planks without the application of odorous adhesives, thus eliminating the volatile organic compounds (VOCs) emitted by these liquid adhesives.

It’s easy to use, creates less mess and provides greater flexibility for installation, repair or selective replacement.

Patented Design

The MaxTab installation system offers superior adhesion and is designed to perform in high temperatures and humidity. Its patented design allows it to resist solvents in cleaning products. The tiles and carpet planks are firmly bonded and hold to the floor after installation, even on uneven surfaces.

Learn more about its design +

Patented Design

The MaxTab installation system offers superior adhesion and performance in spite of high temperatures and humidity. Its patented design allows it to resist solvents in cleaning products. The carpet tiles are firmly bonded and hold to the floor after installation, even on uneven surfaces.

Learn more about its design +
Resistant to moisture and heat
The silicone adhesive provides superior adhesion in high temperature and high humidity environments.
Environmental benefits
Easy product replacement due to no adhesive applied. Keeps the product intact when installed or uninstalled. It allows you to perform selective replacement to minimize losses if part of your flooring needs to be replaced.
Time saving
This is some text inside of a div block.
Easy Installation
Extremely simple to install. It only takes a few minutes to understand the installation system. No specialized machinery or equipment is required.
Durable and Stable
Highly resistant to humidity, high temperature and solvents. MaxTab will maintain its adhesion and will not shrink over time, keeping carpet tiles firmly bonded and on the floor throughout the life cycle of the product.
Low VOC emissions
Avoids the use of toxic adhesives, thus contributing to a considerable reduction in the presence of volatile organic compounds in the air, thus providing a healthier living environment for your health.
Environmental benefits
Easy product replacement due to no adhesive applied. Keeps the product intact when installed or uninstalled. It allows you to perform selective replacement to minimize losses if part of your flooring needs to be replaced.
Resistant to moisture and heat
The silicone adhesive provides superior adhesion in high temperature and high humidity environments.
Time saving
This is some text inside of a div block.
Easy Installation
Extremely simple to install. It only takes a few minutes to understand the installation system. No specialized machinery or equipment is required.
Durable and Stable
Highly resistant to humidity, high temperature and solvents. MaxTab will maintain its adhesion and will not shrink over time, keeping carpet tiles firmly bonded and on the floor throughout the life cycle of the product.
Low VOC emissions
Avoids the use of toxic adhesives, thus contributing to a considerable reduction in the presence of volatile organic compounds in the air, thus providing a healthier living environment for your health.
Moisture and heat resistant
The silicone adhesive provides superior adhesion in high temperature and high humidity environments.
Environmental benefits
Easy product replacement due to no adhesive applied allows you to perform partial replacement to minimize losses if part of your floor covering needs to be replaced.
Time saving
Allows a fast and efficient installation and reduces waiting time before occupying your spaces compared to an installation with glue.
Easy installation
Extremely simple to install. It only takes a few minutes to understand the installation system. And no specialized equipment is required.
Durable and stable
Highly resistant to moisture, high temperature and solvents, MaxTab will maintain its adhesion and will not shrink over time, keeping tiles firmly bonded and to the floor throughout the life cycle of the product.
Low VOC emissions
Avoids the use of toxic glue, thus contributing to a considerable reduction in the presence of volatile organic compounds in the air and offers you a healthier living environment.

Moisture and heat resistant

Ecological

Time saving

Easy Installation

Durable and stable

Low VOC emissions

Patented Design

MaxTab consists of a single-layer polyester tape with a thick, conformable layer of high adhesion silicone adhesive. The adhesive adheres strongly to uneven surfaces and excludes water. It is highly resistant to all solvents and detergents.

MaxTab also includes a single layer polyester high temperature silicone tape that adheres to the most difficult surfaces in high temperature environments.

The third layer of MaxTab is a single-sided polyester tape with a highly effective acrylic adhesive that adheres well to low energy surfaces and does not shrink.

Silicone adhesive provides superior adhesion in high temperature applications. The durable polyester film is resistant to tearing and punctures, chemicals, drip, seepage and slippage. Acrylic adhesive provides excellent initial tack and adhesion; the thick layer of adhesive conforms to uneven surfaces to provide a firm bond.

Economic benefits
"Using MaxTab can save up to 50 % in cost and time compared to other flooring installation methods."
See the different scenarios

The advantages of MaxTab in terms of saving time and money compared to conventional solutions, such as the use of carpet glue. It is easy to use, creates less damage and offers greater flexibility for installation, repair or selective replacement.

Below we present you with different scenarios to show you in concrete terms what the use of MaxTabs can mean in terms of money and time saved.

*Please note that not all jobs require the same preparation and labour costs may vary as well as materials depending on the manufacturer.

Scenario 1: Bonded Vinyl VS MaxTab

Based on a 100 feet X 50 feet square room (Total of 5,000 square feet.

Glued Vinyl

Lift and discard existing glued vinyl at $1.40 / sq. ft.:
$7,000 Manufacturer's Exclusive Standard
Adhesive at $0.29 / sq. ft.:
$1,450
Installation of carpet tile adhesive at $1.75 / sq. ft.:
$8,750

Total time of 3 days; One day for lifting and disposal, 2 days for installation
.

MaxTab

No lifting and removal of old flooring:
$0
No adhesive required:
$

0
Application of topcoat at $0.75 / sq. ft.:
$1,250
2,000 MaxTabs at $0.29 / adhesive:
$580
Installation of carpet tiles at $1.50 / sq. ft.:
$7,500

No lifting, removal. Total duration is 2 days.

$7,870
1
Saving in material and labour costs
Installation day saved

Scenario 2: Wet Concrete Floor

Based on a square room of 100 feet X 50 feet (Total of 5,000 square feet).

Wet Concrete Floor

Very wet flooring with Mapei MSP adhesive at $0.65 / ft² (MSP is a two coat process with a drying time of 1 to 3 hours):
$3,250
Exclusive adhesive supplied by the manufacturer at $0.29 / ft²:
$1,450
Installation of carpet tile adhesive at $1.75 / ft²:
$8,750 Total

time of 3 days; One day for primer, 2 days for installation

MaxTab

2,000 MaxTabs at $0.29 / sticky:
$580
Installation of carpet tiles at $1.50 / sq.ft:
$7,500 Total

duration is 2 days
.

$5,370
1
Saving in material and labour costs
Installation day saved

Scenario 3: Raw concrete, ceramic, V.C.T.
substrate

Based on a square room of 100 feet X 50 feet (Total of 5,000 square feet).

Raw concrete, ceramic, V.C.T.
substrate

Skim bed substrate with Mapei and polymer patch @ $0.75 / sq. ft.:
$3,750
Standard manufacturer's exclusive adhesive at $0.29 / sq. ft.:
$1,450
Installation of carpet tile adhesive at $1.75 / sq. ft.:
$8,750

Total time of 3 days; 1 day for cementing, 2 days for installation
.

MaxTab

2,000 MaxTabs at $0.29 / sticky:
$580
Installation of carpet tiles at $1.50 / sq. ft.:
$7,750

No lifting, disposal. Total duration is 2 days.

$5,870
1
Saving in material and labour costs
Installation day saved

Ecological Benefits

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Suspendisse varius enim in eros elementum tristique. Duis cursus, mi quis viverra ornare, eros dolor interdum nulla, ut commodo diam libero vitae erat. Aenean faucibus nibh et justo cursus id rutrum lorem imperdiet. Nunc ut sem vitae risus tristique posuere.

17000$
1
This is some text inside of a div block.
This is some text inside of a div block.

Permafuse XL

AN IDEAL FLOOR COVERING SOLUTION FOR CORRIDORS

PermaFuse XL is the ideal flooring solution for corridors and large spaces. It consists of long strips of carpet made of stain-resistant nylon, 2 metres wide, with a backing of inseparable, closed-cell layers offering many advantages, including a tight border between the carpet and the floor, and adhesion to the floor without the use of glue.

It installs quickly on any surface and is easy to maintain and replace when needed.

  • Improved acoustics;
  • Superior strength for high traffic areas;
  • Moisture barrier;
  • Simple and easy maintenance;
  • Low VOC emissions - Green Label Plus certified;
  • Improved air quality by reducing airborne particles;
  • Easy installation, repair and replacement;
  • Optimal comfort underfoot;
  • Reduced risk of falling.

When Two Become One

Based on proven technology in the modular carpet industry, our PermaFuse XL rolls are equipped with PermaFuse backing technology, bringing our backing for carpet tiles and carpet planks to a whole new level of performance and durability.

More information +

When Two Become One

Based on proven technology in the modular carpet industry, our PermaFuse XL rolls are equipped with PermaFuse backing technology, taking our carpet backing to a whole new level of performance and durability.

More information +
Installation System
FuseMax seaming tape and SealMax seam sealer allow you to complete any installation without the use of adhesives, while avoiding the need to test for water vapor emission rate (WET) or relative humidity (RH).
Learn more about fuse MAX and seal max

PermaFuseXLTM, combined with Venture Carpet's MAX advanced installation system - including FuseMax seaming tape and SealMax seam sealer - allows you to complete any installation without the use of glue. When using this installation system, testing for Water Vapor Emission Rate (WET) or Relative Humidity (RH) is not required, provided no liquid or moisture spots are present on the surface prior to installation.

The result will be a high-performance and aesthetically pleasing "floating" floor surface. PermaFuseXLTM's selection of styles and colors allows for great creative versatility while harmonizing with our tiles and carpet planks. All of these benefits make PermaFuseXLTM the ideal product for schools, health care facilities and seniors' residences.

Installation Instructions

How to install your carpet tiles and planks

Download our installation guides or watch our instructional videos below.

INSTALLATION GUIDE FOR TILES AND CARPET PLANKS

Our installation guide for installing your floor with MaxTab adhesive tabs

CARPET TILE INSTALLATION VIDEO
Français
CARPET PLANKS INSTALLATION VIDEO
Français
French
French
INSTALLATION VIDEO FOR CARPET TILES
INSTALLATION VIDEO FOR CARPET PLANKS

INSTALLATION GUIDE FOR PERMAFUSE XL

Our installation guide for installing your carpet strips with FuseMax seaming tape and SealMax seam sealer

INSTALLATION VIDEO FOR PERMAFUSE XL ROLL
